MegaPAC L2
Recommended
- Przenośny platforma zoptymalizowana do transmisji i post-produkcji aplikacji
- 2x 23 "LED LCD backlite 16:9 w pełnej rozdzielczości FHD 1920x1080
- Sloty PCI-E v2.0 dla pełnej długości kart rozszerzeń
- Najnowsze procesory i7 Intel ® Core ™ / dual Xeon ®
- Siedem wyjmowalnych kieszeni na napędy 3.5"
Description
The MegaPAC L2 is a unique product. While your average single display system has its limitations, the MegaPAC L2 comes with two 23”, wideview, HD LCD displays to fulfill the requirements of applications that need more perspective.
With 7-expansion slots design, the MegaPAC L2 is an ideal platform for digital media related applications in the broadcasting market. It can also be configured with many special add-on cards for your unique applications and is also typically used in the military field.
The high contrast ratio optimizes viewing when ambient light or sunlight has become distracting. Optional touch screen allows the MegaPAC L2 to operate without keyboard for quicker operations.
Every unit comes equipped with cooling fans and easy access to its expansion slots for immediate system upgrade or maintenance. With its simplistic design and rugged construction, the MegaPAC is the most durable and versatile portable platform for your applications.
MegaPAC L2
Technical Specification
- Dane podstawowe
| DISPLAY | DUAL 23.8" UHD 3840X2160 - 350 NITS (OPTIONAL: 800 NITS - 650 NITS WITH TOUCHSCREEN), OR DUAL 23.8" FULL HD 1920X1080 - 250 NITS (OPTIONAL: 1000 NITS - 800 NITS WITH TOUCHSCREEN), OR DUAL 24" WUXGA 1920X1200 - 250 NITS (OPTIONAL: 1000 NITS) |
|---|---|
| CPU | LATEST SINGLE/DUAL INTEL® XEON, INTEL® CORE, AMD RYZEN™, OR AMD EPYC™ |
| MEMORY | UP TO 1TB DDR4 RAM |
| GRAPHICS CARD | INTEGRATED HD GRAPHIC CONTROLLER OR APPLICATION SPECIFIC GRAPHIC CONTROLLER |
| EXPANSION SLOTS | UP TO 7 |
| STORAGE | UP TO 150TB (REMOVABLE OPTION AVAILABLE) |
| POWER SUPPLY | 850W 100/240VAC, 50/60HZ AUTO-SWITCHING 80 PLUS GOLD RATED OPTIONAL: 1000W OR 1200W 100/240VAC, 50/60HZ AUTO-SWITCHING 80 PLUS PLATINUM RATED (WITH 10 YEAR WARRANTY) OPTIONAL: 28VDC POWER SUPPLY |
| DIMENSIONS | HEIGHT: 16.31" (414MM) WIDTH: 24.58" (624MM) DEPTH: 10.56" (268MM) |
| WEIGHT | ~45 LBS (20KG) |
| TOUCH OPTION | TOUCHSCREEN OPTIONAL |
| WIFI / BLUETOOTH | WIFI AND BLUETOOTH OPTIONAL |
| RAID | |
| RAID 0/1/5/10 </tr="w-1/4">KEYBOARD & MOUSE | 105-KEY KEYBOARD WITH INTEGRATED TOUCHPAD. AVAILABLE IN A VARIETY OF LANGUAGES. |
| TRANSIT CASE | INCLUDES PADDED ROLLING TRANSIT CASE OPTIONAL :HARDENED CASE AVAILABLE |
| QUALITY | ISO 9001 |
| REGULATION | CE, FCC, CCC |
| WARRANTY | 1 YEAR PARTS AND LABOR |
| CUSTOMIZATION | MILITARY CONNECTORS, CUSTOM I/O, TRACKBALL, DUST FILTER, AND MORE. |
